| 원래 장소: | 일본 |
| 브랜드 이름: | Mitsubishi |
| 모델 번호: | FX3U-64MT/DSS |
Description
| Type | Standalone | Number Of Input/Outputs(Point) | 64 |
|---|---|---|---|
| Number Of Inputs(Point) | 32 | Number Of Output Points(Point) | 32 |
| Input specifications | 24 V DC Sink / Source | Output specifications | Transistor (source) |
| Program size(k step) | 64 | RS232 | ○ |
| USB | ○ | Ethernet | ○ |
| Computer Link | ○ | CC-Link | ○ |
| EFI | × | AC Power Supply/DC Power Supply | DC24V |
| CE | ○ | UL | ○ |
| Power Consumption(W) | - | UL, CUL Standards | - |
| KC Standard | - | Notes | Control scale: 16 to 384 points (including CC-Link I/O) (basic unit: 16/32/48/64/80/128 points), 3rd generation micro-sequencer. Achieves a maximum of 384 input/output control points, including a new high-performance machine and remote I/O having a feature of high-speed, high-capacity, high-performance, and functions. Can connect to a range of FX2N special expansion equipment |
The ideal servo family for motion control.
Fast response, high speed, and high accuracy.
• 6 different designs provide a complete range of servo motors to meet the power, speed and performance required per each application.
• Peak torque 300% of nominal during 3 seconds
• Automatic motor recognition by servo drive
• IP67 and shaft oil seal available • High resolution encoders • Absolute multiturn encoder solution • Compact design and robust construction Ratings
• 230 VAC from 30 W to 1.5k W (rated torque from 0.09 to 4.77 Nm) • 400 VAC from 300 W to 55 kW (rated torque from 0.95 Nm to 350 Nm)
Note: The symbols ABC... show the recommended sequence to select the servo motor and cables Servo motor
A Select motor from families SGMAH, SGMPH, SGMGH, SGMUH, SGMSH, SGMBH using motor tables in next pages.
Servo drive
Note: Choosing Sigma-II drive or XtraDrive affects to the encoder cable needed. B Refer to Sigma-II servo drive or XtraDrive chapter for detailed drive specifications and selection of drive accessories.
